[Sumbulbs] Ultra Bright 200W Flip LED Chip COB Light Board 12V DC Fishing Rod Lamp Cold White for Outdoor Camping Lighting Bulb
Caution:Controller packege without Battery!!!
Main Features of Sumbulbs 200W LED COB Light
- COB LED size: 220*113mm
- Emitting diameter: 203*100mm
- Power: 70W
- Voltage: DC 12V – 14V
- Emitting color: Warm White (3000K), Cool whie (6000-6500K)
- RA: 80%
- Luminous efficacy: >100LM/W
- Usage: for fishing rod light, outdoor camping light, car lights and other LED lights
1. Dimmer & Dynamic 2. 8 Dynamic Effects
3. 10-level Dimmer 4. 256-Grade PWM
5. Speed Adjustable 6. Card Type Remote
7. Ultra Slim Design 8. Smooth Dimmer Effect
9. 1 to 1 Remote Paired 10. Auto Save Function
Press this key to turn on unit or switch to standby mode.Unit will turn on and restore to previous status at powering on moment.
Switch to lighting mode from dynamic mode.
3/8/9. Dimmer Adjust Shortcuts
Switch to 100%,50%,or 25% brightness lighting mode.
4/6. Dynamic Mode Adjust
Switch to dynamic mode from lighting mode,or switch between different dynamic modes.
5/7. Speed Adjust
Adjust playing speed of dynamic modes.Press SPEED+ to increase speed and press SPEED- to decrease.
10/11. Brightness Adjust (Dimmer)
Adjust lighting mode brightness.Press BRIGHT+ to increase brightness and press BRIGHT- to decrease.
This unit accepts DC 12V to 14V power supply.The red cable should be connected to positive and black cable to negative.Please select proper power supply according to the LED application.
The red cable should be connected to LED positive and black cable to negative.The peak output current is 6A,please reduce load if main unit is overheating.
CAUTION!Do not short circuit the LED output,this may lead to permanent damage!
Please pull out the insulate part before using.The RF wireless remote signal can pass through barrier,so it’s not necessary to aim at the main unit when operate.For proper receiving remote signal,do not install the main unit in closed metal parts.The remote battery is 3V CR2025 type,please only replace with same type battery.
For more other COB LED Lights, please click the below picture:
COB (Chips on Board) is a new technology of LED packaging of LED light engine. Multi LED chips are packaged together as one light module. When it lights up, it looks like a lighting panel.
How COB LED light source works?
In COB lighting, single LED chips are placed directly on a circuit board (or substrate) which has thermal properties to disperse heat. Heat dissipation is a very important aspect of LED lighting since it can have a major impact on the life expectancy of the luminary. Therefore, COB lighting can have a higher LED chip density and achieve higher light level while maintaining or improving life expectancy.
Advantage of COB:
COB lights are a more efficient form of LED lighting for general or automotive lighting applications because:
- The light has a more uniform appearance
- Better life expectancy
- achieve higher light level over a large area
- COB is more stable and reliable than standard LED package
Shenzhen Sumbulbs Environment Technology Co., Ltd. is a 10-year experieced professional Manufacturer for LED Lighting LED COB and other LED products.
Sumbubls has a complete & scientific Quality Management system, with a number of very experienced engineers and technicians, and is equipped with full of advanced high-tech equipment and production lines.
Sumbulbs mainly focused on the research & development of LED Lighting resource, the designing and producing of LED lights. Products range from COB chip, Ceiling Lights, Spotlights, Crystal Lamp, Tube Lights, Track Lamp, Street Lights, Miner Lamp, Project Lamp, Sunlight Lamp, to Flash Lights etc. Our products are widely used in hotel lighting, room lighting, office lighting, ourdoor lighting and industrial lighting and other lighting projects.
Our products are widely sold to abroad and domestic markets, and got very good high evaluations from our customers.
“Quality First” is always the driving power for Sumbulbs People.
Sumbubls, is on the road to be the next excellent GIANT in the Environment Lighting industry.
